Piezoelectric Products

Us eurotek, inc. Is a proud distributor of piezomechanik products, germany

Highest load actuator for 100 kn load driving voltage -150 thru +700 v full stroke: 220 μm for a 120 mm long element. Preloaded version available.

A "Budweiser" beer-can from southern bohemia for comparison of sizes

You are looking for special drives to produce a motion or a vibration by applying a voltage signal to a piezoactive material?

Yes? Then you have made a real good choice by visiting us.

The PIEZOMECHANIK people have a long experience in designing and manufacturing piezomechanical actuators for various applications ranging from ultrafast piezomechanical firing-pins for rifles to nozzle actuators for newest fuel injection technology to very high load / high power actuators for airframe vibration control. We give you the elements to control laser resonators, to handle optical fibers or to autofocus your microscope. We supply you with PZT's for biological manipulators, for mechanical switches, for tooling machines, for micropumps and, and, and

and electronic supplies

No actuator without electrical supply: from PIEZOMECHANIK you get the widest range of power supplies regarding voltage, current and power for setting up a complete piezomechanical system.

and information

Piezomechanics is a new technology and you have the choice for a lot of configurations to set up a driving mechanism: this is a big chance to come to a smart solution but sometimes this variety is a little bit confusing. No problem: you are not alone!!! Click to Questionary  or E-mail us at sales@useurotek.com and let us talk about your problems, ideas, troubles etc. PIEZOMECHANIK is recommended for its profound consulting.

Actuators

 Cofired monolithic
Cofired monolithic ceramic stacks, rings and chips
  • Bare elements without casing

  • For easy and space-saving mechanical integration

  • Allows highly compact mechanical designs

  • High precision strain gage position detection available

  • Affordable prices

PZT ceramic (lead zirkonium titanium oxide) contains RoHS-relevant lead exemption

Open Product-Details
Piezostacks PSt150
Piezostacks PSt150
  • General purpose stack actuator packages

  • Standard: stainless steel casing, internally preloaded

  • Robust design, easy to handle, wide range of modifications and options

Open Product-Details
Piezo ring
Piezo ring actuators HPSt150 (tubular)
  • Ring actuator package design

  • Standard: stainless steel casing, internally preloaded

  • Robust design, easy to handle, wide range of modifications and options

  • Widely used in transmissive optical arrangements

Open Product-Details
 Frontmount piezo cartridges FPSt 150
Frontmount piezo cartridges FPSt 150
  • Easy to mount piezo actuators via front threading.

  • Widely used for upgrading opto-mechanical arrangements towards highest resolution by retrofitting conventional micrometers

Open Product-Details
Piezo mirror shifters
Piezo mirror shifters STr for optomechanics
  • Easy to mount Ø25mm and Ø35mm short stroke piezo actuators for highly precise moving extended optics like mirrors e.g. in interferometry.

  • Compatible with a lot of opto-mechanical kits.

Open Product-Details
 Accessories
Accessories
  • Useful mechanical components e.g. for easy coupling actuators to external mechanics

  • Various types of electrical extension cables, connectors, adapters

Open Product-Details
DOWNLOAD COMPLETE CATALOG

Electronics

Electrical power supplies
Analogue amplifiers SVR150/x
Analogue amplifiers SVR150/x

Low power for ultra precision positioning

Semi-bipolar wide voltage range: -30 V / +150 V

Current output: up to 60 mA

Very low noise

Open Product-Details
 Analogue amplifier LE150/100
Analogue amplifier LE150/100
  • High power for enhanced dynamics, peak current 1000 mA

  • Very high bandwidth

  • Unipolar output: 0V / +150 V

  • Low noise

Open Product-Details
Strain gage amplifier DMS.X
Strain gage amplifier DMS.X

For operating precision strain gages e.g. for piezo based precision positioning tasks, e.g. feedback closed loop position control

Open Product-Details
 Feedback controllers PosiCon 150/X
Feedback controllers PosiCon 150/X
  • Complete feedback closed loop controller for piezo actuator-strain gage arrangements for closed loop precision positioning

  • Based on PIEZOMECHANIK strain gages

  • Includes strain gage amplifier, feedback electronics and piezo-voltage amplifier

  • Output -30V/+150 for max. stroke

Open Product-Details
On request
  • Electronics for non-standard piezo operating voltages up to 200 V
    e.g. SVR200/x, -50V/+200V, max. current 45 mA
    e.g. LE200/070, 0V/+200V, max.current 700 mA

  • Electronics for even more power / higher current outputs
    for highly dynamic piezo-excitation

DOWNLOAD COMPLETE CATALOG
